Broadcom

Broadcom LSI 9400-8i SATA SAS Host Bus Adapter HBA 12G P24 IT-Mode + 2 cables

Broadcom LSI 9400-8i SATA SAS Host Bus Adapter HBA 12G P24 IT-Mode + 2 cables

Regular price $169.90 USD
Regular price Sale price $169.90 USD
Sale Sold out
Shipping calculated at checkout.
Quantity

This listing is for a bundle with one professional SATA / SAS / NVMe Broadcom 9400-8i host bus adapter as well as two matching miniSAS SFF-8643 to 4xSATA breakout cables (length: 3ft).

The host bus adapter 9400-8i by LSI / Broadcom lets you increase the number of hard drives connected to your server or workstation. The HBA has a PCIe x8 3.0 interface as well as 8 internal ports for SATA or SAS drives via 2x miniSAS SFF-8643 ports. The maximum data transfer rate is 12 GBps. It is universally compatible with all known brands. The HBA is flashed to the latest IT mode firmware for use with ZFS systems like Proxmox, TrueNAS, unRaid, etc. Delivery includes full and low profile brackets for installation.
  • The host bus adapter serves as a hardware interface for storage devices.
  • Ports: PCIe x8 3.1, 2 miniSAS SFF-8643 Ports for up to 8 internal SATA / SAS drives
  • The maximum data transfer rate is 12 Gbps.
  • P24 IT mode firmware (SAS and SATA Profile) is installed.
  • Full and low profile brackets are included.
  • Alternatively labeled as: 9400-8i, 430-8i, 05-50008-01

Specifications

MPN: 05-50008-01
Bus type: PCIe x8 3.0
Interface: SFF-8643
Number of ports: 8
Max. data transfer rate: 12 Gbps
RAID levels: IT mode
Bracket height: Full + Low Profile
Included accessories: SATA / SAS cable(s)
View full details

Collapsible content

Safety Precautions

ATTENTION:

Before changing your system configuration, always back up your data to prevent data loss.

Hardware should only be handled by qualified technicians in an ESD safe environment with ESD safe tools.

Before installing components, always consult the manufacturer’s manual.

CAUTION:

Always turn off the power to your system and remove the AC power cord before installing or removing hardware to avoid experiencing electrical shock or damaging the system.

During operation, heat sinks can heat up significantly. Do not touch them immediately after turning off the power. Leave sufficient time for cooling off before touching them to avoid burns.

Server systems require sufficient ventilation, as provided by a rack case. Insufficient ventilation can cause overheating of components and potentially damage them.
